Thin Partitioned Air Purifier

This thin partitioned air purifier is used to create local clean area thanks to its unidirectional air flow. Wide aluminum-framed HEPA filter provide similar-to-laminar air flow which improves the air flow pattern of local area. Installation methods, mobile, wall-mount, ceiling-mount, are available.

Thin construction. 110mm thick.
Partition. Wide surface (1400*890mm) well partition the work space and create a localized clean area.
Large well sealed aluminum frame filter delivers ISO 5 air near outlet

Download PDF

Products

Set A Consultation Today

Name can't be empty

Email error!

Message can't be empty

Send

*We respect your confidentiality and all information are protected.

General Details

Specification

Reviews

Performance

Cleanliness ISO 5 near the outlet. Cleanliness ISO 7 within room (60m³, running for 60min)
Bacterial removal rate inside aerosol chamber ＞99.99%
Natural airborne microorganism deactivation rate (running for 60 minutes in 100m³ room)＞90.00%

Features

Safe to operate around people; poses no health risks.
Precision-engineered metal housing, durable and resistant to aging. Features bottom air inlet and top air outlet.
Three installation methods available for one machine: mobile, ceiling- and wall-mounting.
Three installation options available: mobile stand, ceiling mount, and wall mount.
Three fan speed settings.
Remote control with built-in magnet that attaches to the device housing.
Manual and scheduled modes provide flexible operation options.
Reservation mode supports programming up to 6 scheduled disinfection sessions.
Modular design facilitates easy maintenance.
Records cumulative operating time and provides automatic maintenance reminders.
Alarms are triggered in case of motor failure, temperature/humidity sensor issues, or communication errors.
The LCD display shows the purifier's status.
